“Say Hello To My Little Friend”: Sheng, a small but fast Deterministic Finite Automaton

May 25, 2018June 4, 2018 geofflangdale12 Comments

Deterministic Finite Automata (DFA, subsequently) are a fundamental structure. Most state machines that programmers build are some variant on a DFA, whether they are built by jumping around inside a switch statement or moving from state to state in a table structure.

They have uses all over the place; they are used heavily in regular expression implementation, and can be used in various validation schemes such as UTF-8 validation. I’m going to show a curious little DFA of my own invention* that we used in Hyperscan**. The presentation here will be an independent re-implementation as the version in Hyperscan is buried in some pretty complex code.

Sheng has some pretty tight limitations, especially in the version I’m presenting here:

It cannot have more than 16 states.
This version of Sheng is ‘quiet’ – it calculates states but doesn’t have an ‘accept state’ that is actively raised. So you can’t detect a regular expression and get a callback or a index as to where it matched.
This version of Sheng is also a bare DFA without a compiler. You need to put the transitions of the state machine in manually.
This version of Sheng depends on x86 instructions, but the principles could allow the extension of Sheng to any system with a similar permute instruction, such as ARM NEON.

Most important: Sheng uses my favorite instruction, PSHUFB!

The Problem in Plain DFA implementations: Memory Latency

A typical problem for DFA implementation is that, at best, each DFA state transition typically involves a single memory access. More compact implementations may use several. Worse still, each of these state transitions depends on the previous state transition, so a simple DFA cannot run faster than the latency of the lowest level of cache (often plus a cycle, if there are things that need to be done to the loaded value from the transition table to make it suitable for another state transition).

This is the critical path of the DFA: the state-to-state transition. Other activities, such as remapping characters to a smaller character set to save space, or checking for accept states, are not on the critical path and are almost ‘free’ in a typical implementation – after all, we’re waiting for the state transition to finish. That’s a lot of free execute slots!

Here’s a not very interesting DFA implementation:

	struct BasicDFA {
	typedef u8 State;
	u8 transitions[16][256];
	State start_state;
	BasicDFA(std::vector<std::tuple<u32, u32, u8>> & trans_vec, u8 start_state_, u8 default_state) {
	…
	}
	State apply(const u8 * data, size_t len, State s) {
	size_t i = 0;
	for (; i+7 < len; i+=8) {
	u8 c1 = data[i+0];
	…
	u8 c8 = data[i+7];
	s = transitions[s][c1];
	…
	s = transitions[s][c8];
	}
	for (; i < len; ++i) {
	s = transitions[s][data[i]];
	}
	return s;
	}
	};

view raw

basicdfa-gist

hosted with ❤ by GitHub

This isn’t a perfect “simple” DFA implementation; we waste at least 1 cycle of latency in our state-to-state transition on index arithmetic to look up that big array (better, but more obscure, would be to track our state as a location within the transition table).

Note the implementation in full unrolls the loop, too.

However, even given a wasted cycle or two of latency, this implementation is close to the limit of memory latency. The DFA is small (4K) so we will be getting it from L1 cache in the steady state, but that means a state-to-state transition at around 4-5 cycles minimum.

Enter My Little Friend: Sheng

Sheng is a different approach. Sheng uses the PSHUFB instruction to implement the state transitions taken by looking up a shuffle mask for each input character. Note that the lookup operation is not on the critical path, as we know our input characters well in advance.

As such, the critical path for Sheng is just 1 cycle on modern architectures; both recent Intel and AMD processors implement PSHUFB with a single cycle of latency.

The variant of Sheng presented is ‘silent’ – it allows us to calculate which state we’re in at a given point but it has no facility to detect whether a match has occurred. We’ll cover the feature of a non-silent Sheng later; sadly, the number of instructions required to check our state means that we will have to add a lot of extra work – too much work to manage 1 cycle per byte (not a critical path issue – it’s just that it’s hard to do that many operations in a cycle).

	struct Sheng {
	typedef m128 State;
	m128 transitions[256];
	State start_state;

	Sheng(std::vector<std::tuple<u32, u32, u8>> & trans_vec, u8 start_state_, u8 default_state) {
	// fill all transitions with default state
	for (u32 i = 0; i < 256; ++i) {
	transitions[i] = _mm_set1_epi8(default_state);
	}
	// fill in state transition for slot 'from' to point to 'to' for our character transition c
	for (auto p : trans_vec) {
	u32 from, to;
	u8 c;
	std::tie(from, to, c) = p;
	set_byte_at_offset(transitions[c], from, to);
	}
	start_state = _mm_set1_epi8(start_state_); // put everyone into start state – why not?
	}

	State apply(const u8 * data, size_t len, State s) {
	size_t i = 0;
	for (; i+7 < len; i+=8) {
	u8 c1 = data[i+0];
	u8 c2 = data[i+1];
	u8 c3 = data[i+2];
	u8 c4 = data[i+3];
	u8 c5 = data[i+4];
	u8 c6 = data[i+5];
	u8 c7 = data[i+6];
	u8 c8 = data[i+7];
	s = _mm_shuffle_epi8(transitions[c1], s);
	s = _mm_shuffle_epi8(transitions[c2], s);
	s = _mm_shuffle_epi8(transitions[c3], s);
	s = _mm_shuffle_epi8(transitions[c4], s);
	s = _mm_shuffle_epi8(transitions[c5], s);
	s = _mm_shuffle_epi8(transitions[c6], s);
	s = _mm_shuffle_epi8(transitions[c7], s);
	s = _mm_shuffle_epi8(transitions[c8], s);
	}
	for (; i < len; ++i) {
	s = _mm_shuffle_epi8(transitions[data[i]], s);
	}
	return s;
	}

view raw

sheng-gist

hosted with ❤ by GitHub

So this one is a little weird: we heavily depend on my favorite instruction, PSHUFB, included on most x86 processors since its introduction with SSSE3 (the catchily named “Supplemental Streaming SIMD Extensions 3”).

PSHUFB (_mm_shuffle_epi8 in this code) is a bytewise shuffle, using the low 4 bits of each byte from a control mask register to indicate which byte to copy from the source register to the destination. It can be used to permute data, but it can also be used to effectively look up a 16-wide table.

In this usage, PSHUFB masks are found on a per-character basis. We look up a character from our input and use this mask to look up what our next state should be. For example, in the 5th unrolled iteration, our current state is used to index into this mask (“transitions[c5]”) and by permuting that mask, and this yields our new state.

We keep our canonical state in the bottom lane of the 128-bit register.

As a side note, we could actually be processing 16 DFAs at once, with an almost useless set of limitations:

The DFAs all have to have the same structure and character transitions.
The DFAs all have to be acting on the same data.

So really, all we can do is start the DFAs off in different states and then crank those states and see what happens. There is an interesting usage of this (picture what happens when we initialize a register with [0,1,2,3,…, 15] and process a block of data – we now have a function that can be applied as another shufle mask! Details can wait for another followup blog post.

So, what do we get from all this? The main advantage of doing this is speed – here’s the basic comparison of speed between the two systems (measured on a 4Ghz Skylake client machine):

	$ sudo nice –20 taskset -c 1 ./sheng

	Sheng
	0/1 1/1 2/1 3/1 4/1 5/1 6/1 7/1 8/1 9/1
	10/1 11/1 12/1 13/1 14/1 15/1 16/1 17/1 18/1 19/1
	20/1 21/1 22/1 23/1 24/1 25/2 26/3 27/4 28/5 29/5
	30/5 31/5 32/5 33/5 34/5 35/5 36/5 37/5 38/5 39/5
	40/5 41/5 42/5 43/5 44/5 45/5 46/5 47/5 48/5 49/5
	50/5 51/5 52/5 53/5 54/5 55/5 56/5 57/5 58/5 59/5
	60/6 61/7 62/8 63/9 64/10 65/1 66/1 67/1 68/1
	final state: 1 bytes scanned: 1638400000 seconds: 0.417347
	bytes per ns 3.92575

	Basic DFA
	0/1 1/1 2/1 3/1 4/1 5/1 6/1 7/1 8/1 9/1
	10/1 11/1 12/1 13/1 14/1 15/1 16/1 17/1 18/1 19/1
	20/1 21/1 22/1 23/1 24/1 25/2 26/3 27/4 28/5 29/5
	30/5 31/5 32/5 33/5 34/5 35/5 36/5 37/5 38/5 39/5
	40/5 41/5 42/5 43/5 44/5 45/5 46/5 47/5 48/5 49/5
	50/5 51/5 52/5 53/5 54/5 55/5 56/5 57/5 58/5 59/5
	60/6 61/7 62/8 63/9 64/10 65/1 66/1 67/1 68/1
	final state: 1 bytes scanned: 1638400000 seconds: 2.73646
	bytes per ns 0.59873

view raw

sheng-output

hosted with ❤ by GitHub

(there’s also a basic-level of traces through states included here so that I could verify that the two state machines are basically sane and doing the same thing; see the code)

So we’re processing 3.92 bytes per nanosecond (pretty close to 1 cycle/byte) as opposed to around 0.6 bytes per nanosecond with a basic DFA implementation (which could probably go about 10-20% faster with a more sophisticated table lookup, but not that much more). Sounds good – as long as we can live with the long list of limitations of Sheng.

Sheng has a lot of interesting properties, which I’ll follow up in later posts:

There are several strategies for having a “noisy” Sheng – that is, one that can stop, raise a callback, or write to a buffer whenever it encounters some “interesting” state (e.g. an accept state).
There are also a number of ways Sheng can be adapted to handle a larger portion of the pattern matching task.
These is nothing inherently x86-centric about Sheng. The TBL instructions on Neon could be used to build up the same facility on ARM, and the multiple register variants of these instructions could be used to build 32, 48 or 64-state DFAs.
An AVX2 machine can run two independent 16-state DFAs at once for the same cost, although there is no cost-free way for them to interact. AVX 512 adaptation of the same techniques allows 4 such independent 16-state DFAs.
AVX512 also allows other exotic structures, including larger DFAs using the 16-bit permute operations, including the 2-source permutes.
AVX512 VBMI adds VPERMB and 2-source byte permutes, allowing this technique to be extended to 64 or even 128 states! However, the added latency of these permutes means that a simplistic implementation will be much slower.
Since PSHUFB is a permute, it’s possible to compute blocks of this operation out-of-order. This can be exploited to improve throughput where latency of an operation is not equal to throughput – this is not true of PSHUFB or VPSHUFB but is true of some of the more recent shuffle instructions (for example, many of the AVX512 16-bit shuffles are latency=7 throughput=2) and will likely be true of the next generation of shuffle instructions.
- Note that a 2-source permute is not straightforwardly handled by this, as in order to turn permutes over a block on input into a function, we must calculate all possible outcomes on all states. This becomes prohibitively expensive with already large operations.
- This out-of-order computation is not particularly suitable where a “noisy” Sheng is required

Until then, I hope you enjoyed Sheng, and you can find the code on Github.

https://github.com/geofflangdale/sheng

[ please note: it is essentially a ‘sketch’, lacking many features and there is approximately zero software engineering applied to it. The Sheng and BasicDFA structures should related through static or dynamic polymorphism so that they can share test drivers, but I didn’t want to start designing a more generalized interface until I have built out more of the Sheng variants, so I used cut-n-paste-polymorphism 🙂 ]

[ also note: yes, there are many ways to make DFAs run faster, including acceleration, gluing the characters together and various other tricks. There are also a bunch of ways to make DFAs run slower; typically by implementing them on specialized hardware add-in cards, then waiting geological ages to get the data to the cards and the matches back. ]

* I independently invented this technique along with some researchers at Microsoft Research; if anyone can recall the paper where this technique is documented, please let me know and I’ll put in a link and appropriate credit.

Update: Anuj Kalia, in comments, identified a Microsoft Research paper that’s possibly what I saw as Data-Parallel Finite-State Machines – Microsoft Research – for the 16-state case, I believe this approach converges to be functionally equivalent to Sheng. We discovered this work only when we went looking to establish originality of Sheng…

** Anatoly Burakov wrote the first implementation of Sheng within Hyperscan. Alex Coyte later extended Sheng to work as part of a much larger DFA, a subsystem which he felt moved to dub “Shengy McShengface”, for reasons he may not be able to adequately explain.

Bits to indexes in BMI2 and AVX-512

May 22, 2018May 22, 2018 geofflangdale10 Comments

[ Please bear with the terrible formatting of the table in this post; I was pretty startled at how limited my options were from a vanilla formatter. Opinions on a better method are welcome. ]

Daniel Lemire, in his post Iterating over set bits quickly (SIMD edition) discusses several techniques to iterate over set bits quickly – or more precisely, to turn a collection of bits into a variable-length buffer full of integers indicating which bits were set.

So, if your code gets given an array with the following 16-bit bitfields (assuming little-endian order):

0x1001, 0x0003, 0xffff

you would want the answer:

indexes = 0, 12, 16, 17, 32, 33, 34, ... , 46, 47

This is an important operation. While it’s a lot of fun to do clever things with SIMD, sooner or later you may need to do something specific with the bits you found in your SIMD registers. For example, we used a number of SIMD techniques in Hyperscan to search for strings, but eventually you would have to report that you’d found something to the rest of the system.

After reading Daniel’s post, and more importantly, taking some time to hack on an AVX-512 system that he generously shared access with me, I think I have invented a new, branch-free way of solving this problem for 64-bit integers. There is the small catch that you will have to have an AVX-512 capable system handy.

(I say I think I invented this as it’s quite possible that (a) I’ve absorbed this technique from somewhere and forgot, or (b) someone else has already independently invented this)

Here’s the technique.

Let’s rig up a bunch of masks with alternating blocks of one and zero bits:

uint64_t msk_1 = 0xffffffff00000000ULL;
uint64_t msk_2 = 0xffff0000ffff0000ULL;
uint64_t msk_3 = 0xff00ff00ff00ff00ULL;
uint64_t msk_4 = 0xf0f0f0f0f0f0f0f0ULL;
uint64_t msk_5 = 0xccccccccccccccccULL;
uint64_t msk_6 = 0xaaaaaaaaaaaaaaaaULL;

Now, suppose I have a bitvector in v that I’d like to turn into a bunch of indexes. I can get a start by doing this:

uint64_t v1 = _pext_u64(msk_1, v);
uint64_t v2 = _pext_u64(msk_2, v);
uint64_t v3 = _pext_u64(msk_3, v);
uint64_t v4 = _pext_u64(msk_4, v);
uint64_t v5 = _pext_u64(msk_5, v);
uint64_t v6 = _pext_u64(msk_6, v);

What did this achieve? Well, suppose I have the 11th bit set in v and nothing else. Looking into my masks, I can see that my PEXT operation (a fast bitwise extract) got me a 1-bit from msk_6, a 1-bit from msk_5, a 0-bit from msk_4, a 1-bit from msk_3 and 0-bits otherwise. These bits will all be deposited into the least significant bits of the v1 through 6 temporaries.

In other works, for each set bit, I’m extracting the bit pattern of its index from the masks and depositing that bit pattern at the lowest-significant bytes on my v1 through v6 temporary values.

So, in the unlikely event that you were hoping to get the right answers, annoyingly bit-smeared across 6 different uint64_t variables, you’re done. But that’s probably not very satisfying. We’ll get to that.

So how do we interleave these 6 values together? This looks pretty ugly – we’re looking at 384 total bits in the worst case of answers. So this doesn’t seem like something we can do fast in the General Purpose Registers. Let’s go to SIMD.

The principle we will apply is that we will use AVX-512’s facility to use 64-bit mask to control a SIMD computation. We will take our 6 values and use them to control the progressive adding of 32, 16, 8, 4, 2 and 1 into a result.

__m512i vec;
vec = _mm512_maskz_add_epi8(v1, v32_bit, _mm512_set1_epi8(0));
vec = _mm512_mask_add_epi8(vec, v2, v16_bit, vec);
vec = _mm512_mask_add_epi8(vec, v3, v8_bit, vec);
vec = _mm512_mask_add_epi8(vec, v4, v4_bit, vec);
vec = _mm512_mask_add_epi8(vec, v5, v2_bit, vec);
vec = _mm512_mask_add_epi8(vec, v6, v1_bit, vec);

Now vec holds the answer we wanted, if we just wanted a bunch of bytes on our output, ranging from 0..63. Unfortunately, we need to write some not very interesting code if we’re doing this over a large range, where we imagine that our offsets might be much larger than a byte. If we’re working continuously over inputs >64K, we would expect to need 4 byte answers. In order to write out up to 64 uint32_t offsets, we’re going to have to spread out our results over 4 registers (spreading the bytes over u32 units), add in a value ‘k’ representing the base offset of our 64-bit value to begin with, and write all 4 of these big registers out.

__m512i base = _mm512_set1_epi32(k*64);
__m512i r1 = _mm512_cvtepi8_epi32(_mm512_extracti32x4_epi32(vec,0));
__m512i r2 = _mm512_cvtepi8_epi32(_mm512_extracti32x4_epi32(vec,1));
__m512i r3 = _mm512_cvtepi8_epi32(_mm512_extracti32x4_epi32(vec,2));
__m512i r4 = _mm512_cvtepi8_epi32(_mm512_extracti32x4_epi32(vec,3));

r1 = _mm512_add_epi32(r1, base);
r2 = _mm512_add_epi32(r2, base);
r3 = _mm512_add_epi32(r3, base);
r4 = _mm512_add_epi32(r4, base);
_mm512_storeu_si512((__m512i *)out, r1);
_mm512_storeu_si512((__m512i *)(out + 16), r2);
_mm512_storeu_si512((__m512i *)(out + 32), r3);
_mm512_storeu_si512((__m512i *)(out + 48), r4);

(note that ‘out’ is a uint32_t so we are actually getting +64, +128, +192 bytes with those last three offsets).

Alert readers will note that this code is writing a lot of stuff out. What happens if we only had 1 bit set? Or 0? Well, this blog isn’t called “Branch Free” for nothing.

More seriously, the point is that it’s usually cheaper to do the same thing every time rather than run the risk of a branch mispredict. Looking back at the code above – sure, it looks like a giant bolus of code. But a branch miss on a modern architecture is around 14 cycles. That’s a lot of missed opportunity to do work.

Even if you accept my above philosophy of doing tons of potentially redundant work over risking a branch miss, there’s one more question – we need to know where our next write should be:

uint8_t advance = __builtin_popcountll(v);
out += advance

That just moves us up (remember ‘out’ is a uint32_t for pointer math purposes) to the last value that actually had something set. And we’re done!

Is it fast?

Here’s a rough spreadsheet of the results measured against several of the other methods described in Daniel’s article. It’s faster than most of the other methods, falling down only for very low ‘bitmap densities’. For these lower densities, taking a conditional branch with the prospect that the expected number of bits set in a word is very low is a winning proposition.

Bitmap density	Method	Cycles per index
0.03	bitmap_decode_ctz	3.852
	bitmap_decode_avx2	10.116
	bitmap_decode_avx2_turbo	14.363
	bitmap_decode_avx2_turbo_thin	15.736
	bitmap_decode_avx2_turbo_nopopcnt	12.624
	bitmap_decode_bmi2_avx512	12.9
0.12	bitmap_decode_ctz	4.97
	bitmap_decode_avx2	3.003
	bitmap_decode_avx2_turbo	4.205
	bitmap_decode_avx2_turbo_thin	4.547
	bitmap_decode_avx2_turbo_nopopcnt	3.732
	bitmap_decode_bmi2_avx512	2.481
0.25	bitmap_decode_ctz	4.251
	bitmap_decode_avx2	1.52
	bitmap_decode_avx2_turbo	2.09
	bitmap_decode_avx2_turbo_thin	2.265
	bitmap_decode_avx2_turbo_nopopcnt	1.861
	bitmap_decode_bmi2_avx512	1.25
0.5	bitmap_decode_ctz	3.446
	bitmap_decode_avx2	0.796
	bitmap_decode_avx2_turbo	1.042
	bitmap_decode_avx2_turbo_thin	1.131
	bitmap_decode_avx2_turbo_nopopcnt	0.92
	bitmap_decode_bmi2_avx512	0.616
0.9	bitmap_decode_ctz	3.037
	bitmap_decode_avx2	0.444
	bitmap_decode_avx2_turbo	0.574
	bitmap_decode_avx2_turbo_thin	0.628
	bitmap_decode_avx2_turbo_nopopcnt	0.509
	bitmap_decode_bmi2_avx512	0.366

Is this a great idea? I don’t know.

There are no doubt other methods to use AVX512 to transform bit vectors in this fashion, and for a relatively low ‘population’ there are a number of ways the bitmap_decode_ctz code can be made to run faster (possibly the topic of another article).

I still think it’s an interesting ‘trick’ and it’s nice to take my second-favorite instruction (PEXT) out for a spin.

Let me know if you’ve seen this trick somewhere before and I’ll be happy to credit where credit is due. As I said, I think I invented it…

The code is available at Daniel Lemire’s Github with an error (my fault, apparently I thought 8+2 = 9) which will be corrected in due course.

ps. In the ‘dynamiting the trout stream’ category, I give you VPCOMPRESSB from Intel® Architecture Instruction Set Extensions Programming Reference (PDF) which will greatly simplify all the above trickery, once we have AVX512_VBMI2 capable machines (Ice Lake time-frame).

pps. There is also a branch-free means where VPCOMPRESSD can be used four times on 16-bit words to solve a similar problem on machines that are publicly available now. This can be left as an exercise for the reader. It might be faster than the BMI2 stuff, but it lacks style points.

Introduction and welcome

May 22, 2018May 22, 2018 geofflangdale2 Comments

Hello, world.

This is my blog where I will talk about things that interest me (and a no doubt small collection of others). Topics that I’m interested in include:

Low-level and performance-oriented programming
Computer architecture (especially as it related to performance-oriented code)
Programming languages
Regular expression implementation and automata theory
… and of course, implementing things without branches! Thus the name.

I was the designer of the Hyperscan project. I built this system at Sensory Networks, which was acquired by Intel Corporation in 2013, and worked on Hyperscan at Intel for over 4 years.

I hope that I can show you some interesting things. I have a few things in the pipeline that I will show shortly, including some string matching work, fast Random Forest implementation and a lot of my favorite low-level coding tips and tricks.

I request that my readers can bear with me and forgive the (hopefully temporary) amateurish nature of the site; I am not an expert blogger or user of WordPress.

The Problem in Plain DFA implementations: Memory Latency

Enter My Little Friend: Sheng

Share this:

Like this:

Share this:

Like this:

Like this:
